Audio Perfection at a perfect price

Let's face it, we love our Raspberry Pi but audio quality is just bad or inexistant (PiZero). RaspiAudio enables your Raspberry Pi ( Pi 3, 2, B+, A+, and Zero) with a state of the art audio DAC at a reasonable price.

Great for home audio sound sytem, internet radio, or any project with audio at a price that makes sense.

Just plug your Raspberry Pi Audio on top of your Raspberry PI Pi 3, 2, B+, A+, and Zero and let the music blast.













Let's get technical

  • 24-bit audio with studio sampling quality
  • The 5th-order noise shaper operates at 64fs
  • Line out stereo jack
  • Optional landing for dual RCA phono connector
  • DAC over the Raspberry Pi's I2S interface
  • Compatible with Raspberry Pi 3, 2, B+, A+, and Zero
  • Female header requires soldering

Let's install it

-Solder the included 40pins header (black part on the bottom):

For Raspian users:

-Insert your Rapsberry Pi Audio Shield in your Raspberry pI then turn it on

-Make sure your audio jack is plugged in to your amplifier

-Open a terminal (yes the black windows thing) and type:

sudo wget -O - install.raspiaudio.com | bash

-You might have to reboot

-If everything went fine you should here a test sound when tryping this command:

sudo speaker-test -l5 -c2 -t wav

For references here is the script source.



For OSMC users:

Just follow each steps and device name of this tutorial



Following GPIOs are used by RaspiAudio:

-GPIO21 (pin 40)

-GPIO19 (pin 35)

-GPIO18 (pin 12)

-Ground pin (connect at least one : pin 6, 9, 14, 20, 25, 30, 34, 39)

-3.3v pin (connect at least one: : pin 1, 17)

All others pin are free to use in your projects!
